Reactivity Intro

Reactivity overview

Agenda

Reactivity overview
How do other frameworks work?
Reactive programming
Walking the graph
Your turn
Conclusion

How did Shiny do that?

View the app on this page:

105-reactivity

...

How did Shiny do that?

We told Shiny what to do
We didn’t tell Shiny when to do it

How do other frameworks work?

Agenda

Reactivity overview
How do other frameworks work?
Reactive programming
Walking the graph
Your turn
Conclusion

How do other frameworks work?

Other web application frameworks use event-driven programming:

Streamlit
- Re-render everything everywhere all the time
Dash / Panel / Gradio
- Define callback functions

Using callback functions is hard!

Every callback introduces side effects
Callbacks are hard to reason about, hard to compose
Bugs are subtle, conditional on sequences of events
In short: “callback hell”

# This is not how shiny works!
library(gWidgets)
txt <- gtext("Customize me", container = gwindow(),
  handler = function(h, ...) {
    # Do something in response to text changing
  }
)
btn <- gbutton("Click me", container = gwindow(),
  handler = function(h, ...) {
    # Do something in response to a button click
  }
)

Event driven programming: summary

You have to do it
Easy to get wrong
Hard to tell when you get it wrong

Reactive programming

Agenda

Reactivity overview
How do other frameworks work?
Reactive programming
Walking the graph
Your turn
Conclusion

Is there a better way?

Note

Infer the relationships between components
Build a computation graph

The better way: reactivity

Shiny does not infer relationships by analyzing the source code
- Many ways that would break down!
Not static analysis, but rather, runtime tracing
- The underlying mechanism is simple, reliable, and intuitive
- The shiny team have more than 10 years of real-world experience with this form of reactivity

Drawing a reactive graph

Shiny express app:

from shiny.express import input, render, ui

ui.input_slider("n", "N", 0, 100, 20)
@render.text
def txt():
    return f"2 * n is {input.n() * 2}"

Reactive graph:

Walking the graph

Agenda

Reactivity overview
How do other frameworks work?
Reactive programming
Walking the graph
Your turn
Conclusion

Initial state

Calculate the text

Final state

Slider changes

Invalidates

Forget dependencies

Recalculate

Recompute the graph

Updated state

Your turn

Agenda

Reactivity overview
How do other frameworks work?
Reactive programming
Walking the graph
Your turn
Conclusion

Your turn

Draw the graph of this application:

View the app on this page:

200-penguins

...

Hint: you need 4 elements and draw the arrows between these.

Solution: Initial state

Solution: Calculate scatter plot

Solution: Calculate distribution

Solution: Reactive graph

Solution: Slider changes

Solution: Invalidated

Solution: Forget dependencies

Solution: Recalculate

Solution: Updated

Solution: Checkbox changes

Solution: Invalidated

Solution: Forget dependencies

Solution: Recalculate

Solution: Updated

Conclusion

Agenda

Reactivity overview
How do other frameworks work?
Reactive programming
Walking the graph
Your turn
Conclusion

Summary: reactive programming

Tell Shiny how each output should be filled
Trust that the framework will keep everything up-to-date
You’re setting the menu, not doing the cooking
